Waterworks Inventory

Waterworks Inventory

Watershed
   - China Creek basin 6202 Ha
   - Bainbridge Lake Catchment 1310 Ha

Intakes (Surface Supply) 3
   - China Creek - gravity  24,451 m3/day permit
   - Bainbridge Lake - pumped 9,763 m3/day permit
   - Somass River - pumped 13,564 m3/day permit
    Total Permitted Volume 47,778 m3/day permit

Dams   3
   - China Creek - intake - concrete  El. 184m (603.7') 5000 m3 storage
   - Lizard Lake -concrete/earthfill (440 acre ft) El. 732m (2401.6') 578,000 m3 storage
   - Bainbridge Lake - earthfill (1000 acre ft) El.153m (502') 1,230,000 m3 storage
  1813000

Pumpstations 5
   - Bainbridge - 2x50 HP @ 2508 gpm  100 Hp

   - Somass     - 2x60 HP @ 750 gpm ea. 245 Hp
                         - 1x125 HP @ 1390 gpm

   - Cowichan   - 2x60 HP @ 2400 gpm 125 Hp
                           - 1x5 HP @ 65 gpm

   - Johnston   - 4x60 HP @ 800 gpm ea. 538 Hp
                          - 1x7.5 HP @ 120 gpm
                          - 2x145 HP diesel @ 2100 gpm

   - Arrowsmith - 2x5 HP @ 65 ea. 10 Hp

   Total Pumpstation Horsepower 1018 Hp

Chlorination Stations 3
   - Bainbridge Pumpstation (gas injection)
   - Somass Pump/Intake (gas injection)
   - Johnston Pumpstation (gas injection)

Chlorine Residual Test Points - Daily 13
Bacterial Test Locations - Monthly 21

Reservoirs 5
   - Upper Cowichan - floating cover  El.158m 11,250 m3    1962/1963
   - Lower Cowichan - floating cover El.146m 6,750 m3     1937
   - Burde - floating cover El.86.8m 6,750 m3     1947
   - Johnston - 2 cells, concrete  El.66.8m 9,000 m3
   - Arrowsmith - 1 cells, steel tank  El.173.6m 250 m3
   Total Reservoir Storage Volume 34,000 m3

Supply mains HDPE- 500mm 3.60 km
Supply mains Steel - 1200mm 0.10 km
Supply mains PVC- 500mm 1.51 km
Supply mains steel- 600mm 4.81 km
Total Supply Mains 10.02

Distribution mains < 150mm 91.0 km
Distribution mains 200-300mm 48.5 km
Distribution mains > 300mm 25.5 km
Total Distribution Mains 165.0 km

Distribution mains - Asbestos Cement 77.2 km
Distribution mains - Cast Iron 32.3 km
Distribution mains - P.V.C. 37.6 km
Distribution mains - Ductile Iron 7.6 km
Distribution mains - Galvanized Iron 0.0 km
Distribution mains - Steel 0.8 km
Distribution mains - Wood Stave 0.0 km
Distribution mains - Type Unknown 9.5 km
  165.0

Pressure Reducing Stations 20
Pressure Zones 12
Line Valves 1618
Air Valves 69
Hydrants (City) 735
Hydrants (Private) 74

Connections  6462
   - Residential
   - Commercial 317
   - Industrial 13
   - City 64
  6856

Meters (Active) 6856

Meter Size Breakdown
15 or 19 mm inside City 6432
15 or 19 mm outside City 50
25mm inside 100
25mm outside 1
40mm inside 82
40mm outside 2
50mm inside 127
50mm outside 5
75mm inside 30
75mm outside 2
100mm inside 11
100mm outside 1
150mm inside 6
150mm outside 4
over 150mm 3
  6856

Average Annual Volume Served 5,836,317 m3
Peak Day Usage 18,072 m3
Minimum Day Usage 2,731 m3
Average Day Usage 9,216 m3
